The liquid crystal display module and the liquid crystal module refer to components for assembling a liquid crystal display device, a connecting member, a peripheral circuit for controlling and driving, a PCB circuit board, a backlight, and a structural member.
The technical specifications of the liquid crystal display module (LCM) currently available from Xin Hongtai are as follows:
The number of dot matrix is: 122*32, 128*64, 160*32, 256*32, 192*64, 240*64, 160*128, 240*128, 256*128, 320*240, 640*200, etc. Product
Working temperature: normal temperature 0 ~ +50 ° C, wide temperature -20 ~ +70 ° C, ultra wide temperature -30 ~ + 80 ° C;
Interface type: 3-wire or 4-wire SPI serial port, 8-bit or 16-bit MCU parallel port, I2C, RS232 or RS485, USB interface;
Display mode: black on white, black on yellow and green, black on blue, white on blue, white on black, custom silk screen, etc.
| Checklist | Model | Product type | Show contents | Product map |
Outline size (mm) |
Horizon (mm) |
Display size mm/inch |
Point spacing mm |
Visual angle | Brightness | Pin | Interface | Instructions | Working temperature | Voltage | Driver chip model |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 3-inch LCD128x64 graphic LCD module | Blue text on gray background | 128X64 graphic LCD display HTM12864-27-11W-A5P | Graphic LCD Module | 128x64 |
|
93.0x70.0x13.5 | 65.5x38.0 | 60.775x32.935 | 0.475x0.515 | 6H | white | 20PIN | SPI | Anti-static ESD 8KV | -20~70℃ | 5.0V | ST7565R | |
| 3-inch 128x64LCD graphic LCD module 128X64 graphic LCD display | DFSTN negative display white backlight | ST7565R controller HTM12864-27-41W-A5P | Graphic LCD Module | 128x64 |
|
93.0x70.0x13.5 | 65.5x38.0 | 60.775x32.935 | 0.475x0.515 | 6H | white | 20PIN | SPI | Anti-static ESD 8KV | -20~70℃ | 5.0V | ST7565R | |
| 3-inch 128x64 graphic LCD |128X64 graphic LCD display | STN negative display white backlight HTM12864-27-25W-A5P | Graphic LCD Module | 128x64 |
|
93.0x70.0x13.5 | 65.5x38.0 | 60.775x32.935 | 0.475x0.515 | 6H | white | 20PIN | SPI | Anti-static ESD 8KV | -20~70℃ | 5.0V | ST7565R | |
| 3-inch 128x64 graphic LCD module | 12864LCM | STN positive display yellow-green backlight | ST7565R controller HTM12864-27-01Y-A5P | Graphic LCD Module | 128x64 |
|
93.0x70.0x13.5 | 65.5x38.0 | 60.775x32.935 | 0.475x0.515 | 6H | YG | 16PIN | SPI | Anti-static ESD 8KV | -20~70℃ | 5.0V | ST7565R | |
| 2.0 inch LCD graphic screen/128x64 graphic dot matrix LCM/red, green and blue backlight/MCU/ST7565 HTM12864-23-35S-A3P | Graphic LCD Module | 128x64 |
|
54.6x50.0x9.1 | 45.2x27.0 | 40.93x24.29 | 0.38x0.32 | 6H | R/G/B | 16PIN | MCU | Anti-static ESD 8KV | -20~70℃ | +3.3V | ST7565 | |
| 2.0 inch LCD graphic module/128x64 dot matrix yellow-green graphic LCD/STN+/3.3v/MCU interface HTM12864-23-11Y-A3P | Graphic LCD Module | 128x64 |
|
54.6x50.0x9.1 | 45.2x27.0 | 40.93x24.29 | 0.38x0.32 | 6H | YG | 16PIN | MCU | Anti-static ESD 8KV | -20~70℃ | +3.3V | ST7565 | |
| 2.0-inch 128x64 LCD graphic LCD module/128x64 graphic dot matrix module/MCU interface/3.3v HTM12864-23-11W-A3P | Graphic LCD Module | 128x64 |
|
54.6x50.0x9.1 | 45.2x27.0 | 40.93x24.29 | 0.38x0.32 | 6H | white | 16PIN | MCU | Anti-static ESD 8KV | -20~70℃ | +3.3V | ST7565 | |
| 2.0 inch 128x64 dot matrix graphic LCD module/ST7565 control chip/3.3V/5.0V/black background with white characters/Arduino/MCU HTM12864-23-41W-A3P | Graphic LCD Module | 128x64 |
|
54.6x50.0x9.1 | 45.2x27.0 | 40.93x24.29 | 0.38x0.32 | 6H | white | 16PIN | MCU | Anti-static ESD 8KV | -20~70℃ | +3.3V | ST7565 | |
| 2.0-inch graphic dot matrix module/128x64 graphic LCD module/ST7565 driverchip/gray text on white background HTM12864-23-31W-A3P | Graphic LCD Module | 128x64 |
|
54.6x50.0x9.1 | 45.2x27.0 | 40.93x24.29 | 0.38x0.32 | 6H | white | FPC-16PIN | MCU | Anti-static ESD 8KV | -20~70℃ | +3.3V | -20~70℃ | |
| 2.0-inch 128 x 64 graphics dot matrix module/128x64 resolution/ST7565 control chip/MCU HTM12864-23-01Y-A3P | Graphic LCD Module | 128x64 |
|
54.6x50.0x9.1 | 45.2x27.0 | 40.93x24.29 | 0.38x0.32 | 6H | YG | FPC-16PIN | MCU | Anti-static ESD 8KV | -20~70℃ | +3.3 V | ST7565 |
